The butterfly valve is operated by a pneumatic actuator consisting of a metal disc that rotates around the body and initiates a sealing ring around the circumference of its elastic seat. The stem can be centrally mounted or offset mounted. There is also a packing unit that provides an additional sealing ring for protection in the event that the rubber seat is damaged by fire. Since it is a quarter valve, you only need to rotate the handle 90 degrees to fully open the valve.
In large plants such as refineries and power generation facilities, a high performance butterfly valve can be seen with a gearbox actuator and flywheel connection through its body. These are motorized valve actuators that initiate automatic valve opening and closing. Some of these valves have a switch so you can remotely monitor the position of the disc. So the function of the flywheel in this type of system is for emergency reasons when there is no power.
List of Pneumatic actuator operated butterfly valve
Features
- Valve Size : 3″ / 80mm
- End Connection : Wafer – API 609 (CAT – A)
- Actuator : Type – Double Acting / Size – 50
- Attachments : Namur Solenoid Valve & Limit Switch
- Body Material : CI Body (FG210)
- Disc Material : SS304
- Stem Design / Material : Single Shaft / ASTM A 276 TYPE SS 410
- Seat Material : EPDM
- Pressure Rating : PN10
Uflow 3 Inch / 80mm Pneumatic Actuator Operated CI Butterfly Valve PN10 with Solenoid Valve 230v AC
Features
- Valve Size : 3″ / 80mm
- End Connection : Wafer – API 609 (CAT – A)
- Actuator : Type – Double Acting / Size – 50
- Attachment : Namur Solenoid Valve
- Body Material : CI Body (FG210)
- Disc Material : SS304
- Stem Design / Material : Single Shaft / ASTM A 276 TYPE SS 410
- Seat Material : EPDM
- Pressure Rating : PN10
