Uflow 1/4 Inch 3/2 Way Direct Acting Solenoid Valve Brass Body (0 – 10 Bar) with Metallic Round Coil – Normally Close
₹1,270.00 – ₹1,400.00 (-20%)
Features:
- Size : 1/4″BSP
- Coil Type : Metallic Round Coil with Lead Wire
- Valve Type : 3/2 way Normally Closed Screwed End
- Body Material : Forged Brass
- Pressure Range : 0 to 10 kg/cm2 (bar)
- Temperature (Media) : -30° C to 90° C
- Seal : Nitrile (NBR)
- Media : Suitable for Air, Gas
- Other Specification / Data : Check the tabs given below for details
Description
| Port | Refer technical data sheet (Available in BSP threading) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| End Connection | Screwed | ||||||||||
| Body Material | Forged Brass | ||||||||||
| Diaphragm |
|
||||||||||
| Media Temp. | |||||||||||
| Circumstance Temp. | -10° C to 70° C | ||||||||||
| Media | Air, Gas | ||||||||||
| Main Features | Internal Parts are in superior corrosion resistance steel, (Equivalent to SS316L) Suitable for Food Industries, Pharmaceuticals, Chemical application & Highly corrosive environment | ||||||||||
| Operating Voltage |
|
||||||||||
| POWER CONSUMPTION | |||||||||||
| COIL FEATURES | High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as require. | ||||||||||
| COIL TYPES | Epoxy Moulded Coil with LED, Metallic Round Coil with Wire, Metallic Round Coil with LED, IP-68 Weather Proof Coil, IP-67 Flame Proof Coil, Power Saver Coil | ||||||||||
| OPTIONAL FEATURE | 90% Power saver series also available, Manual Override, Water hammering reducer also available to avoid water hammer forces. | ||||||||||
| OTHER SPECIFICATION DATA | Available on Request |
NOTE1: Seal – NBR as standard. Rest – Optional
NOTE2: Use of filter in the inlet port is recommended.
Dimension
| Model No. | Port Size | A | B | C | E | E1 |
|---|---|---|---|---|---|---|
|
TBN14
|
1/4"
|
43
|
89
|
80
|
44
|
57
|
Technical Data
| Model No. | Body Material | Pipe (Inch) | Orifice (mm) | Min. Operating Pressure Kg/cm² | Max. Operating Pressure Kg/cm² | Seal & Diaphrgm Material | Flow Factor Kv m³/hr |
|---|---|---|---|---|---|---|---|
| TBN14 | Forged Brass | 1/4″ | 1.5 | 0 | 10 | NBR | 0.07 |
* Note – Seal : EPDM / Viton / PTFE / Silicon on request
