Uflow Fast OPEN-CLOSE Founatin Application Diaphargm Solenoid Valve 1.1/2 Inch 2/2 Way SS304 with Metallic Round Coil

Uflow Fast OPEN-CLOSE Founatin Application Diaphargm Solenoid Valve 1.1/2 Inch 2/2 Way SS304 with Metallic Round Coil

Brand UFLOW

₹ 5835 (Incl. of all taxes)

₹ 4945 + ₹ 890 GST

MRP ₹7293

Select Options:

230 v AC

24 v AC

110 v AC

12 v DC

24 v AC

Offers and Coupons

Save instantly 2% with online payment.

via UPI, EMI, Credit/Debit Card, Net Banking, Wallets.

Get flat Rs. 100 OFF

Min cart value ₹10,000

INDUSO100

Click to Copy

Get GST invoice and save up to 18% on business purchases

VIEW

Brand Warranty

100% Genuine Products

Safe & Secure Payment

Nationwide Delivery

Multi-Brands

Weight	1.85 KG

PORT

Refer technical data sheet (Available in BSP threading)

END CONNECTION

Screwed

BODY MATERIAL

SS ASTM A351 Grade CF8

DIAPHRAGM
MEDIA TEMP.

Nitrile (NBR)	EPDM	Viton (FKM)
-30° C to 90° C	-10° C to 140° C	-10° C to 180° C

MEDIA

Air, Water, Chemical, Gas

MAIN FEATURES

Valve opens and closes very fast hence preferred for musical fountain applications and other similar applications where quick on-off function is required.

OPERATING VOLTAGE
POWER CONSUMPTION

24AC	110AC	230AC	12DC	24DC
7W	8W	8W	10W	11W

COIL FEATURES

High reliability unaffected by voltage surges. Easy coil change. Coil lockable in 4 x 90° position or freely movable in between as required.

OTHER COIL TYPES

Epoxy Moulded Coil with LED, Metallic Round Coil with LED, IP-68 Weather Proof Coil, IP-67 Flame Proof Coil, Power Saver Coil

OPTIONAL FEATURE

90% Power saver series also available, Manual Override, Water hammering reducer available to avoid water hammer forces.

OTHER SPECIFICATION DATA

Available on Request

NOTE: Use of filter in the inlet port is recommended.

Model No.	FCN68
Body Material	CF8 (SS304)
Pipe Size (Inch)	1.1/2"
Orifice (mm)	36
Min. Operating Pressure (kg/cm²)	0.5
Max. Operating Pressure (kg/cm²)	12
Seal & Diaphragm Material	NBR
Flow Factor Kv (m³/hr)	17.10

* Note – Body Material : CF8M (SS316) on request, Seal : EPDM / Viton on request

Size	1.1/2"BSP
Coil Type	Metallic Round Coil with Lead Wire
Valve Type	2/2 way Normally Closed Screwed End
Body Material	SS304 (ASTM A351 Grade CF8)
Pressure Range	0.5 to 12 kg/cm2 (bar)
Temperature (Media)	-30° C to 90° C
Seal	Nitrile (NBR)
Media	Suitable for Air, Water, Chemical, Gas
Application	General Purpose and Fountain Application
Other Specification / Data	Check the tabs given below for details
