Uflow 3/4 Inch 2/2 Way Semi-Lift Diaphragm Operated Solenoid Valve SS304 with Metallic Round Coil - Screwed Ends

Uflow 3/4 Inch 2/2 Way Semi-Lift Diaphragm Operated Solenoid Valve SS304 with Metallic Round Coil - Screwed Ends

Brand UFLOW

₹ 2944 (Incl. of all taxes)

₹ 2495 + ₹ 449 GST

MRP ₹3679

Select Options:

230v AC

24v DC

110v AC

12v DC

24v AC

Offers and Coupons

Save instantly 2% with online payment.

via UPI, EMI, Credit/Debit Card, Net Banking, Wallets.

Get flat Rs. 100 OFF

Min cart value ₹10,000

INDUSO100

Click to Copy

Get GST invoice and save up to 18% on business purchases

VIEW

Brand Warranty

100% Genuine Products

Safe & Secure Payment

Nationwide Delivery

Multi-Brands

Weight	1.25 KG

Port

Refer technical data sheet (Available in BSP threading)

End Connection

Screwed

Body Material

SS ASTM A351 Grade CF8

Diaphragm & Media Temp.

Nitrile (NBR)	EPDM	Viton (FKM)	PTFE
-30° C to 90° C	-10° C to 140° C	-10° C to 180° C	-10° C to 180° C

Circumstance Temp.

-10° C to 70° C

Media

Air, Water, Chemical, Gas, Oil, Steam. LPG

Main Features

Internal Parts are in superior corrosion resistance steel, (Equivalent to SS316L) Suitable for Food Industries, Pharmaceuticals, Chemical application & Highly corrosive environment

Operating Voltage & Power Consumption

24AC	110AC	230AC	12DC	24DC
7W	8W	8W / 15W	10W	11W

Coil Features

High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4×90 position or freely movable in between as require.

Coil Types

Epoxy Moulded Coil with LED, Metallic Round Coil with Wire, Metallic Round Coil with LED, IP-68 Weather Proof Coil, IP-67 Flame Proof Coil, Power Saver Coil

Optional Feature

90% Power saver series also available, Manual Override, Water hammering reducer also available to avoid water hammer forces.

Other Specification Data

Available on Request

NOTE 1: Seal - NBR is standard. Rest - Optional

NOTE 2: Use of filter in the inlet port is recommended.

Model No.	MCN33
Body Material	CF8 (SS304)
Pipe Size (Inch)	3/4"
Orifice (mm)	20.00
Min. Operating Pressure (kg/cm²)	0
Max. Operating Pressure (kg/cm²)	7
Seal & Diaphragm Material	NBR
Flow Factor Kv (m³/hr)	5.00

Note: Body Material : CF8M (SS316) on request, Seal : EPDM / Viton / PTFE on request

Size	3/4"BSP
Coil Type	Metallic Round Coil with Lead Wire
Valve Type	2/2 way Normally Closed Screwed End Gravity Pressure Valve
Body Material	SS304 (ASTM A351 Grade CF8)
Pressure Range	0 to 7 kg/cm2 (bar)
Temperature (Media)	-30° C to 90° C
Seal	Nitrile (NBR)
Media	Suitable for Air, Water, Chemical, Gas
Other Specification / Data	Check the tabs given below for details
