Uflow 3/4 Inch 2/2 Way Semi-Lift Diaphragm Operated Solenoid Valve SS304 with Epoxy Moulded LED Coil - Screwed Ends

Uflow 3/4 Inch 2/2 Way Semi-Lift Diaphragm Operated Solenoid Valve SS304 with Epoxy Moulded LED Coil - Screwed Ends

Brand UFLOW

₹ 2772 (Incl. of all taxes)

₹ 2349 + ₹ 423 GST

MRP ₹3464

Select Options:

230v AC

24v DC

110v AC

Offers and Coupons

Save instantly 2% with online payment.

via UPI, EMI, Credit/Debit Card, Net Banking, Wallets.

Get flat Rs. 100 OFF

Min cart value ₹10,000

INDUSO100

Click to Copy

Get GST invoice and save up to 18% on business purchases

VIEW

Brand Warranty

100% Genuine Products

Safe & Secure Payment

Nationwide Delivery

Multi-Brands

Weight	1.2 KG

Port

Refer technical data sheet (Available in BSP threading)

End Connection

Screwed

Body Material

SS ASTM A351 Grade CF8

Diaphragm & Media Temp.

Nitrile (NBR)	EPDM	Viton (FKM)	PTFE
-30° C to 90° C	-10° C to 140° C	-10° C to 180° C	-10° C to 180°

Circumstance Temp.

-10° C to 70° C

Media

Air, Water, Chemical, Gas, Oil, Steam, LPG

Main Features

Internal parts are in superior corrosion-resistant steel (equivalent to SS316L). Suitable for food industries, pharmaceuticals, chemical applications & highly corrosive environments.

Operating Voltage & Power Consumption

24AC	110AC	230AC	12DC	24DC
7W	8W	8W / 15W	10W	11W

Coil Features

High reliability, unaffected by voltage surges. Easy coil changes; coil lockable in 4 × 90° positions or freely movable in between as required.

Coil Types

Epoxy moulded coil with LED, metallic round coil with wire, metallic round coil with LED, IP-68 weather-proof coil, IP-67 flame-proof coil, power saver coil.

Optional Feature

90% power saver series available, manual override, water hammering reducer to avoid water hammer forces.

Other Specification Data

Available on request

NOTE 1: Seal – NBR is standard. Others optional.

NOTE 2: Use of filter in the inlet port is recommended.

Model No.	MCN33
Body Material	CF8 (SS304)
Pipe Size (Inch)	3/4"
Orifice (mm)	20.00
Min. Operating Pressure (kg/cm²)	0
Max. Operating Pressure (kg/cm²)	7
Seal & Diaphragm Material	NBR
Flow Factor Kv (m³/hr)	5.00

Note: Body Material : CF8M (SS316) on request, Seal : EPDM / Viton / PTFE on request

Size	3/4"BSP
Coil Type	Epoxy Moulded Square Coil with LED DIN Connector
Valve Type	2/2 way Normally Closed Screwed End Gravity Pressure Valve
Body Material	SS304 (ASTM A351 Grade CF8)
Pressure Range	0 to 7 kg/cm2 (bar)
Temperature (Media)	-30° C to 90° C
Seal	Nitrile (NBR)
Media	Suitable for Air, Water, Chemical, Gas
Other Specification / Data	Check the tabs given below for details
