Uflow 2 Inch / 50mm Pneumatic Actuator Operated CI Butterfly Valve PN10 with Limit Switch and Solenoid Valve 24v DC

Uflow 2 Inch / 50mm Pneumatic Actuator Operated CI Butterfly Valve PN10 with Limit Switch and Solenoid Valve 24v DC

Brand UFLOW

₹ 7922 (Incl. of all taxes)

₹ 6714 + ₹ 1208 GST

MRP ₹9902

Select Options:

230v AC

24v DC

110v AC

12v DC

24v AC

Offers and Coupons

Save instantly 2% with online payment.

via UPI, EMI, Credit/Debit Card, Net Banking, Wallets.

Get flat Rs. 100 OFF

Min cart value ₹10,000

INDUSO100

Click to Copy

Get GST invoice and save up to 18% on business purchases

VIEW

Brand Warranty

100% Genuine Products

Safe & Secure Payment

Nationwide Delivery

Multi-Brands

Weight	5 KG

DESIGN STANDARD	IS 13095, Bi-directional zero leakage butterfly valve
END CONNECTION	Wafer end
OPERATOR	Actuator Operated
MOUNTING	Can be mounted between flanges as per ASME, BS-10 and ISO Pad for actuator
FLANGE ACCOMMODATION	ANSI B16.5 150#, BS10 TABLE E, TABLE F, TABLE H
LEAKAGE CLASS	100% tightness at full differential Pressure.
DISC ROTATION	360 Degree
TESTING	100% tested under Water and Pneumatic
PRESSURE RATING	PN10 & PN16
NOMINAL DIAMETER	DN50 - DN200

NOTE: Other options of Seat Material / Pressure Range / Body Material and Additional Attachments only on request.

No Technical Data Available

Valve Size	2" / 50mm
End Connection	Wafer - API 609 (CAT - A)
Actuator	Type - Double Acting / Size - 50
Attachments	Namur Solenoid Valve & Limit Switch
Body Material	CI Body (FG210)
Disc Material	SS304
Stem Design / Material	Single Shaft / ASTM A 276 TYPE SS 410
Seat Material	EPDM
Pressure Rating	PN10
