Uflow 1 Inch 2/2 Way High Temperature Semi-Lift Diaphragm Operated Solenoid Valve for Steam, Hot Fluid SS304 with Metallic Round Coil - Screwed Ends

Uflow 1 Inch 2/2 Way High Temperature Semi-Lift Diaphragm Operated Solenoid Valve for Steam, Hot Fluid SS304 with Metallic Round Coil - Screwed Ends

Brand UFLOW

₹ 4364 (Incl. of all taxes)

₹ 3698 + ₹ 666 GST

MRP ₹5455

Select Options:

230v AC

24v DC

110v AC

12v DC

24v AC

Offers and Coupons

Save instantly 2% with online payment.

via UPI, EMI, Credit/Debit Card, Net Banking, Wallets.

Get flat Rs. 100 OFF

Min cart value ₹10,000

INDUSO100

Click to Copy

Get GST invoice and save up to 18% on business purchases

VIEW

Brand Warranty

100% Genuine Products

Safe & Secure Payment

Nationwide Delivery

Multi-Brands

Weight	2 KG

PORT

Refer technical data sheet (Available in BSP threading)

END CONNECTION

Screwed

BODY MATERIAL

SS ASTM A351 Grade CF8

DIAPHRAGM
MEDIA TEMP.

Viton (FKM)	PTFE
-10° C to 180° C	-10° C to 180° C

CIRCUMSTANCE TEMP.

-10° C to 70° C

MEDIA

Steam, Hot Water, Air, Chemical, Gas

MAIN FEATURES

Internal parts are in superior corrosion resistance steel (Equivalent to SS316L). Suitable for Food Industries, Pharmaceuticals, Chemical applications & highly corrosive environments.

OPERATING VOLTAGE
POWER CONSUMPTION

24AC	110AC	230AC	12DC	24DC
7W	8W	8W / 15W	10W	11W

COIL FEATURES

High reliability unaffected by voltage surges. Easy coil change. Coil lockable in 4 × 90° positions or freely movable in between as required.

COIL TYPES

Epoxy Moulded Coil with LED, Metallic Round Coil with LED, IP-68 Weather Proof Coil, IP-67 Flame Proof Coil, Power Saver Coil

OPTIONAL FEATURE

90% Power saver series also available, Manual Override, Water hammering reducer available to avoid water hammer forces.

OTHER SPECIFICATION DATA

Available on Request

NOTE 1: Seal - PTFE as standard. Rest - Optional.

NOTE 2: Use of filter in the inlet port is recommended.

Model No.	MCNP413
Body Material	CF8 (SS304)
Pipe Size (Inch)	1"
Orifice (mm)	25
Min. Operating Pressure (kg/cm²)	0
Max. Operating Pressure (kg/cm²)	4
Seal & Diaphragm Material	PTFE
Flow Factor Kv (m³/hr)	8.20

* Note – Body Material : CF8M (SS316) on request, Seal : VITON on request

Size	1"BSP
Coil Type	Metallic Round Coil with Lead Wire
Valve Type	2/2 way Normally Closed High Temperature Screwed End Gravity Pressure Valve
Body Material	SS304 (ASTM A351 Grade CF8)
Pressure Range	0 to 4 kg/cm2 (bar)
Temperature (Media)	-10° C to 180° C
Seal	PTFE
Media	Suitable for Steam, Hot Water, Air, Chemical, Gas
Other Specification / Data	Check the tabs given below for details
